TIA-606 Cable Color Codes & Labeling Standard

Standard color conventions for structured cabling.

TIA-606-B (and its successor TIA-606-C) is the standard that keeps a structured cabling plant legible: a color code so technicians can identify the function of a cable run at a glance, plus a labeling and identifier scheme so every cable, patch panel, and pathway has a unique, documented address. Blue is horizontal workstation drops, orange marks the demarcation point, white and gray distinguish backbone levels, purple is common equipment, and red is reserved for critical circuits.

The color code is only half the standard. TIA-606 also defines an identifier format for cables and panels (such as the telecom room and port number that appears on a label), and organizes a facility into administration classes that scale from a single closet to a multi-building campus. Documenting cable colors alongside labels - as the Cable Label template does - makes troubleshooting a cable plant dramatically faster.

Color	Use	Standard
Blue	Horizontal cabling (workstation drops)	TIA-606-B
Yellow	Auxiliary circuits / security / alarms	TIA-606-B
Orange	Demarcation point (telco / ISP handoff)	TIA-606-B
Green	Network connections (switch-to-patch panel)	TIA-606-B
Red	Key telephone systems / critical circuits	TIA-606-B
White	First-level backbone (MC to IC)	TIA-606-B
Gray	Second-level backbone (IC to HC)	TIA-606-B
Purple	Common equipment (PBX, LANs, muxes)	TIA-606-B
Brown	Inter-building backbone (campus)	TIA-606-B
Black	Miscellaneous / special circuits	TIA-606-B

Frequently Asked Questions

What is the TIA-606 standard?

TIA-606 (now TIA-606-C) is the Administration Standard for Commercial Telecommunications Infrastructure. It defines the labeling, color coding, identifier formats, and record-keeping needed to manage a structured cabling plant, so every cable, panel, and pathway has a unique identifier and a documented record.

What are the TIA-606 cable color codes?

TIA-606-B assigns colors to cable functions: blue for horizontal workstation drops, orange for the demarcation point, white and gray for first- and second-level backbone, purple for common equipment, red for critical circuits, yellow for auxiliary circuits, green for network connections, brown for inter-building backbone, and black for miscellaneous circuits.

What is the difference between TIA-606-B and TIA-606-C?

TIA-606-C, published in 2017, is the current revision of the administration standard. It refines the identifier and labeling requirements introduced in TIA-606-B, adds guidance for newer cabling environments, and is the version to reference for new installations and documentation projects.
